Arcolectric now offer an integral moulded guard for its 1550 and 1350 range of double pole rocker switches. The guard is an extension of the rocker switch bezel on two sides and is designed to reduce the possibility of accidental switch operation.

This option can also be used with an additional hinged cover to provide even more protection against accidental operation of the switch. The cover is available in various colours to suit the switch body colour or transparent polycarbonate for use with illuminated switches, allowing visual confirmation of switch status without having to open the protective cover.

These two new product variants are available for Arcolectric’s double pole 1550 and 1350 series, on all switching operations in the L style bodies, which fit into 30mm x 22mm panel cut-outs.

This simple addition to the switch body extends the useful application of this product into areas where security or safety of switch operation is of paramount importance.

The 1500 series of switches have ratings up to 16(4)A 250Vac with a wide choice of terminal options, alternative switching circuits including 3 position types with a variety of rocker switch profiles, body sizes and bezels. The 1350 is a high in-rush version rated at 150A to EN61058-1. Matching indicators are also available to complete the range.

Enquiry Form: http://www.epreston.co.uk/enquiries.html

Home Page: http://www.epreston.co.uk/epblog/

Arcolectric’s 8200 & 8300 Miniature Push Button switch ranges now have higher current ratings. Both ranges have been re-assessed for ENEC approval to 12(12)A 250Vac at 105?C for 10,000 operations.

The extensive 8300 range is available with either illuminated or non-illuminated buttons, in single or double pole with momentary or latching switch action. There are options for various switching functions, terminal styles – including push on, solder and PCB terminals, along with options for actuators, body finish, colours and legend printing.

The 8200 range is sub panel mount with a choice of actuator types and terminal styles and orientation, these include push-on, solder and PCB terminals.

Both ranges have UL & CSA approval, as well as ENEC approval to the new higher current rating.

This higher inductive rating further extends the applications for these two families of switches into motor switching applications where the initial switching current can be far higher than a resistive load.

Enquiry Form: http://www.epreston.co.uk/enquiries.html

Home Page: http://www.epreston.co.uk/epblog/

Arcolectric’s latest addition to its extensive range of Indicators are the new slim profile LED Holders.

With significantly smaller mounting hole sizes compared to the standard range of LED holders, these holders push fit to panel allowing quick and easy assembly.

The 1035 holders are suitable for use with T1 type LED’s (4.5mm) and the 1036 and 1037 for T1 3/4 type LED’s (6 and 6.35mm versions). Maximum panel thickness is 1.6mm.

The LED holders are available with bare LED leads or with wire termination, and can be supplied pre wired for 2, 6, 12, 24 or 28V dc and 125 or 250V ac. The LEDs are available in red, green, blue or yellow as standard, however dual colour options are available upon request. They can also be supplied without LEDs fitted.

This range of LED holders are ideal for use where panel size is at a premium or where a large quantity of LED’s are required to be densely mounted together.

Enquiry Form: http://www.epreston.co.uk/enquiries.html

Home Page: http://www.epreston.co.uk/epblog/

The latest edition of the Arcolectric Catalogue is now available. Catalogue 170 includes full specifications, detailed drawings and photographs for all the current Arcolectric products.

There are many new products included in the new 108 page catalogue:

• 6100 IP67 sealed rocker switches
• 3900 IP67 sealed toggle switches
• 4151 key operated pushbutton
• 0566 6mm miniature indicators
• Slimline LED holders
• IP67 sealed indicators
• IP67 sealed low voltage lampholders
• Maintenance Indicator
• Temperature monitor
• Status monitor
• Mains supply checker single phase
• Mains monitor dual phase
• Mains monitor three phase
• Temperature micro logger
• Compact cooker hood controller

Packed with information for designers, engineers and specifiers, Catalgue 170 is available in printed and CD versions.

Enquiry Form: http://www.epreston.co.uk/enquiries.html

Home Page: http://www.epreston.co.uk/epblog/

Arcolectric’s extensive range of panel mounted indicators has been further expanded with the introduction of a new miniature indicator.

Fixing into a 6mm diameter panel hole, this compact push-fit indicator has three lens options; low profile, domed and high profile. An optional chrome bezel is also available and iIllumination is by dc LED, mains LED or neon lamp.

Available in five colours; clear, red, green, amber and blue, the 0566 can be supplied with either 2.8mm tags or flying leads. Approvals are expected from Semko and UL.

This new miniature indicator will find numerous applications where space is at a premium or a number of indicators need to be placed in very close proximity to one another.

Enquiry Form: http://www.epreston.co.uk/enquiries.html

Home Page: http://www.epreston.co.uk/epblog/

New to Arcolectric’s range of Push Button switches is the 4100 Series Key Operated Push Button switch. With up to 100,000 mechanical operations this switch is suitable for frequent functional use.

These switches are ideal for use in applications such as vending machines. Where the maintenance locking key can be used to retain the switch connnection by depressing the plunger enabling the power to be maintained whilst the door is in the open position.

The 4100 series is available with single or double pole switching with momentary action plunger operation and either 4.8 or 6.3mm faston connections.

The large over-travel feature built into the 4100 Series Switches allows it to accommodate substantial production tolerances.

This switch is rated up to 16.5A 400Vac T85 and has ENEC approval to 50,000 electrical operations. The panel cut out size is 37 x 13.5mm, however this switch can also be screwed to the panel on 22mm fixing centres.

Also available for use with the 4100 Series is a separate connector block. This reduces assembly time by allowing the wiring to become an integral part of the wiring harness.

Enquiry Form: http://www.epreston.co.uk/enquiries.html

Home Page: http://www.epreston.co.uk/epblog/

New to Arcolectric’s extensive range of rocker switches is the 6100 IP67 panel sealed version.  This neat, compact, sealed rocker switch will maintain sealing characteristics of the equipment without the use of external covers. Ingenious internal sealing provides the necessary seal while still maintaining a strong tactile feel.

Although external switch covers can be used to provide environmental sealing, they can often obscure the switch status and give an indistinct switching action, Arcolectric’s new switch solves these problems.

Rated at 16(6)A, 250Vac T125, this single pole switch is available in non-illuminated or LED illuminated versions, both types carry ENEC approval.

The compact ‘L’ body profile has a 30 x 11mm panel cut-out with snap-to panel fixing, accommodating 1.0 to 3.0mm panels and is supplied complete with panel gasket; no extra sealing accessories are required. Terminals are 6.3mm faston tabs.

The switches are ideal for use in equipment that will be used in environments where ingress into equipment’s could affect its operation.

Enquiry Form: http://www.epreston.co.uk/enquiries.html

Home Page: http://www.epreston.co.uk/epblog/

Arcolectric’s latest design is a new toggle switch with integral IP67 sealing.

The new 3900 switch, with body designation ‘E’ for single pole and ‘F’ for double pole, incorporates internal and external seals to provide panel sealing to IP67. This eliminates the need to fit additional clumsy toggle covers, therefore making the switch straightforward to use and quicker to assemble.

Rated at 20A, 277Vac, it is available with ON-OFF, ON-ON and three position ON-OFF-ON switching. The panel mounting hole is the industry standard 12.7mm diameter, terminals are 6.3mm tabs or solder tags and the levers manufactured from nickel plated brass.

This new version of Arcolectric’s popular 3900 series is ideal for both internal and external applications where the environmental integrity of the equipment must be maintained against the ingress of dust or water.

Enquiry Form: http://www.epreston.co.uk/enquiries.html

Home Page: http://www.epreston.co.uk/epblog/

Arcolectric have introduced the Temperature Micro-Logger, an intelligent panel mounted device that monitors and stores temperatures for downloading over a wireless data link.

The device is ideal for applications where monitoring process temperature is important, particularly within the food preparation industry. It is especially useful for food storage, retail displays and prepared food outlets where accurate record keeping is essential. The Temperature Micro-Logger adds advanced logging functionality to a food storage unit for little cost increase, much smaller than would be expected by the end user.

The Micro-Logger provides a clear and simple visual indication of the temperature conditions within the piece of equipment, utilising a simple go/no-go display principal. Blue LED illumination indicates when process temperatures are within safe limits. The display changes to a Red indication if the safe temperature limits are ever exceeded. Temperature measurement range can be set between -30ºC and +80ºC.

Designed for quick installation, the Micro-Logger has an industry standard snap-in profile, with a temperature sensor on flying leads for convenient remote mounting. The product can directly replace the mains neon indicator usually found on freezers, refrigeration and cold storage equipment, providing a fast, cost-effective upgrade of non-compliant or un-monitored equipment.

The temperature data is logged into an internal non-volatile memory at user programmable time intervals ranging from 1 second to 12 hours. Up to 14,000 measurements can be stored. The data can be downloaded via the built-in wireless infrared communication port using a PDA, Notebook or laptop computer and is time and date stamped, simplifying reporting and providing documented evidence of historical storage temperatures.

Retailers and producers need to ensure food products are kept at the recommended safe temperatures, and for self-protection, adequate temperature records must be kept. Complying with the relevant food storage regulations does not lay with the equipment manufacturer; it is the responsibility of the equipment end user. The addition of the Micro-logger to an item of food storage equipment enables manufacturers to supply added value to end users, and a facility to contribute to complying with the regulations.

The Micro-Logger carries UL, CE and FCC approvals

Enquiry Form: http://www.epreston.co.uk/enquiries.html

Home Page: http://www.epreston.co.uk/epblog/


New from Arcolectric is a range of smart indicators – intelligent devices that operate like standard neon indicators, but with added functionality. The intelligent embedded microcontroller can be programmed for multiple applications, and the first three offerings from this family are a Single phase supply checker, a Maintenance indicator and a Temperature monitor.

The indicators have the familiar and convenient snap-in profile and feature fast-on terminals, so are drop-in replacements for Neon lamps, making it simple and fast to upgrade an existing product design with new functionality. The smart indicators feature dual LED illumination, so there is a wide choice of illumination colours and colour combinations.

Single phase supply checker (C1431AL)
The supply checker can be fitted as a direct replacement for a Neon indicator, giving clear visual equipment safety indication. The device connects to Live, Neutral and Earth terminals, and monitors the appliance and incoming mains supply for swapped or missing electrical connections. Blue LED illumination indicates correct connections, while Red LED illumination indicates a swapped connection fault. A flashing Red LED indicates a missing connection, such as detached neutral or earth.

Intended for use on appliances or equipment where cable damage is a possibility, such as: portable appliances, site equipment, power tools, garden equipment, extension cable reels, audio equipment, commercial kitchens and stainless steel appliances.

Maintenance indicator (C1432AL)
The indicator monitors appliance usage, and operates as a preventative maintenance or regular inspection reminder for the equipment user. A direct replacement for a neon indicator, the unit counts time that mains power is applied, and remembers the accumulated time even if power is switched off. Blue LED illumination indicates normal operation, but when the factory set operating time is exceeded the illumination changes to flashing Red, indicating that service or maintenance action is required. Connecting the ‘reset’ terminal to neutral resets the timer to zero, and timing starts again.

Typical domestic applications are reminding coffee machine users to decalcify their machines, change deep fat fryer oil, and change or clean cooker hood filters. For service interval indication, the unit could be fitted into gas appliances to indicate when servicing or inspection is overdue. Additionally, users could be given an indication when their appliance warranty period is about to expire.

Temperature monitor (C1433AL)
The temperature monitor is a snap-in device to clearly indicate that refrigeration temperatures are within safe limits. Upper and lower temperature limits can be factory programmed to suit the application. The monitor operates like a standard neon indicator, giving visible on/off status indication for the appliance. Normal operation shows continuous blue LED illumination while the monitored temperature is within the ‘safe’ range between lower and upper limits. Should the measured temperature fall outside of the ‘safe’ range, the LED illumination changes colour to Red. The unit has a pre-connected temperature sensor on a flying lead, ready for quick installation.

Intended for convenient monitoring of deep freeze, refrigeration, cold storage, chiller or air conditioning operation, giving a visual check of the correct temperature without having to know the exact temperature or the limits.
