For almost every industrial sensing requirement, Eaton’s Electrical Sector is now offering dependable, easy-to-use and cost-effective solutions. The company’s latest range of sensing products is exceptionally comprehensive and includes not only inductive sensors with cylindrical and square housings, but also capacitive sensors, an extensive family of optical sensors, and mechanical limit switches with plastic and metal bodies.

Eaton has also published a new brochure detailing its sensor products, entitled ‘Versatility in the Range -Flexible, Robust, Innovative’, which is available free on request or can be downloaded instantly from the Eaton website at (http://www.moeller.net/en/support/related_downloads.jsp?group=dlg_23718).  The publication reference is W1300-7618en.

Eaton offers its inductive sensors in five different series. The E52 and E56 series cube and pancake sensors are shock resistant and have an IP66 or better ingress protection rating, making them ideal for use in tough environments. Global series cylindrical sensors for standard applications are available in M8, M12, M18 and M30 versions and are offered in both ac and dc versions, while for applications demanding extra performance, Eaton supplies iProx and E57Premium+ inductive sensors.

Available with stainless steel housings from 4 mm to 30 mm in diameter, iProx and E57Premium+ sensors feature enhanced noise immunity, and a 360º LED visible from any angle for output status indication. In addition, users of the innovative iProx types can access extra functions with a simple programming tool. This includes adjusting both the sensing band and noise immunity, converting from Normally Open to Normally Closed, and even applying time delays and simple logic functions. The iProx software contains an extensive database of competitor models and enables those looking for replacement sensors to clone iProx to the nearest match.

Eaton optical sensors are also available in cylindrical and cube formats and can be supplied in versions for through-beam, polarised reflex and diffuse reflective applications. Over 30 models in the range include Perfect Prox technology, which provides effective background rejection that’s easy to set up. In addition, cube format models in the SM series feature the microprocessor-controlled TargetLock system that ensures fast set up and optimum performance whatever the application.

Capacitive sensors from Eaton are primarily intended for the detection of non-metallic targets, including liquids and granulated or powdered materials. They are offered in plastic-bodied cylindrical versions, and can be supplied for use with either ac or dc supplies.

For applications where conventional mechanical limit switch sensing is preferred, Eaton offers two versatile product ranges. LS-Titan limit switches are available with either metal or plastic bodies and feature interchangeable heads for maximum versatility, while the rugged Global E50 products feature a rugged design that makes them ideal for heavy-duty use.

Sealed effectively against the ingress of dust and liquids, including cleaning agents, lubricants, cutting oils and coolants, Global E50 limit switches can be supplied with pressure or rotary-function heads, and are complemented by a large variety of optional operating rods and levers.

.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Hylec-APL has launched a new series of lockable door enclosures to complement its growing range of electrical housings. Manufactured by Hylec-APL company, DE Controls, these lockable enclosures are constructed from a flame proof material with galvanised steel back plates and mounting brackets.

* IP65 ingress protection.
* IK08 combustible standards.
* 3 - 3.5mm wall thickness provides rugged protection.
* Available in sizes ranging from 200 x 300 x 130mm to 500 x 700 x 250mm.
* Standard operating temperature range: -20˚C to 85˚C.
* Available with transparent polycarbonate door where required.
* Suitable for internal and external applications.

.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

The revolutionary SmartWire-DT system from Eaton’s Electrical Sector, which virtually eliminates the need for conventional control wiring in panels and on machines, is now even more versatile and convenient. This follows the addition of devices with integral SmartWire-DT connectivity to two key product ranges – easy800 control relays and PKE motor-protection circuit breakers.

In many applications, easy800 programmable control relays with SmartWire-DT make it possible to implement sophisticated control systems without the need to use programmable controllers (PLCs), which means big savings in costs and complexity. In addition, Eaton’s easySoft-Pro software makes easy800 relays simple to program, even for users who have no specialist programming knowledge or experience.

The new easy800 relays are suitable for applications with up to 320 I/O and are programmed using straightforward and well-known ladder diagram techniques. The easySoft-Pro programming software now includes SmartWire Assist to configure external devices, allowing control systems that incorporate the new relays to be drawn, configured, programmed and tested using just this one intuitive software package.

Equally well suited for use in control systems based on easy800 relays, and those based on conventional PLCs, PKE motor-protection circuit breakers with SmartWire-DT allow users to monitor the operation of their motors in detail and in real time. The PKE units can report via the SmartWire-DT connection a wide range of operating parameters that include motor current, motor fault conditions and overload status. This is achieved without the need for additional hardware like current transformers and specialist relays, which are not only costly to buy, but are also inconvenient to fit and wire.

A key benefit of the information supplied by PKE units with SmartWire-DT connectivity is that, in many cases, it allows developing problems to be identified and addressed before a motor trip occurs, thereby greatly reducing downtime and costly production losses.

SmartWire-DT from Eaton is a powerful and versatile communications system that enables switching and control devices, such as contactors, circuit breakers and pushbuttons, as well as analogue I/O devices, to be connected quickly and simply using pre-fabricated plug-in cables. This saves time in building and testing control systems, as well as virtually eliminating the risk of wiring errors while greatly increasing the ease with which future modifications can be made.

.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Robust, Instant Connections for Harsh Environments

The all metal construction 6000 Series Buccaneer - circular connectors that combine the ease of use of a push/pull coupling mechanism with proven environmental sealing for signal and mains power.

Designed and independently tested to IP66, IP68 & IP69K standards, they are ideal for applications where ingress of dust and water must be avoided and where ease of connection, space and appearance are important considerations.

For Power
Metal Version

CLICK HERE FOR BROCHURE —>  Bulgin 6000 Series Buccaneer For Power - Metal Version

* Push/pull locking mechanism - Secure, instant locking. Quick connector mating and release
* 30° twist locking - Tamperproof lock prevents accidental un-mating
* IP66, IP68 and IP69K when mated - Suitable for a wide range of dust and water borne environments
* All metal body version; brass, nickel plated - Robust construction offering protection against EMI
* Flex, flex in-line & panel mount body styles, with sealing caps - Complete family of products maintain sealing integrity in all styles
* Polarisation and visual alignment features - Aids the correct mating of connectors
* 2 to 22 poles – up to 16A, 277V rated - Suitable for mains power to signal applications
* ‘Scoop proof’ contacts - Prevents damage through mis-mating – ideal for ‘blind mating’ applications
* Cable braid termination accessory - Maintains continuity between cable screen and connector body
* cULus, VDE, CCC approvals (pending) - Internationally recognised certification

6000 Series Buccaneer - specially designed for a broad range of harsh environment applications, including:

* Industrial Automation – assembly systems, conveyors, factory automation, motion and process control, factory peripherals, industrial computers, industrial controllers, testing, measurement and inspection equipment, vision systems
* Lighting – temporary lighting, external illumination, signage, architectural lighting
* Food Processing – feeding and packaging, weighing, inspection, testing, printing equipment
* Materials Handling – automatic or manual lifts, table lifts, weighing, inspection equipment
* Transportation – special vehicles, GPS location systems, control equipment, traffic control
* Marine – lighting, control wiring and navigation equipment
* Security – alarm beacons, CCTV, detection systems
* Networking – LAN and wireless equipments
* Renewable energy – solar inverters

.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Robust, Instant Connections for Harsh Environments

6000 Series Buccaneer - circular connectors that combine the ease of use of a push/pull coupling mechanism with proven environmental sealing. Available with metal or plastic bodies, the range supports Ethernet and USB data interfaces.

Designed and independently tested to IP66, IP68 & IP69K standards, they are ideal for applications where ingress of dust and water must be avoided and where ease of connection, space and appearance are important considerations.

For Data — Ethernet
Thermo-Plastic & Metal Versions

CLICK HERE FOR BROCHURE —>  Bulgin 6000 Series Buccaneer for Data Ethernet

* Push-pull locking system - Secure, instant locking. Quick connector mating and release
* 30° twist locking - Prevents accidental un-mating
* IP66, IP68 and IP69K when mated - Suitable for a wide range of dust and water borne environments
* Independent sealing tests - IP Ratings independently verified
* Cat 5e compliant - Data rate up to 100MHz
* PUR jacket on cable - Good chemical resistance, flame retardan
* Shielded system - High noise immunity and EMI protection
* Cat 5e shielded coupler - Maintains shielding
* Visual mating indication - Alignment indicator reduces risk of damage during mating
* Rewireable flex connector - Ability to ‘field’ terminate
* Earth lead version of panel adaptor on plastic connector - Continuous screening of panel mount connector
* Metal connector grounded to cable screen - Continuous screening of panel mount connector
* Sealed through panel Ethernet - Prevent water ingress into equipment

6000 Series Buccaneer - specially designed for a broad range of harsh environment applications, including:

* Industrial Automation – assembly systems, conveyors, factory automation, motion and process control, factory peripherals, industrial computers, industrial controllers, testing, measurement and inspection equipment, vision systems
* Lighting – temporary lighting, external illumination, signage, architectural lighting
* Food Processing – feeding and packaging, weighing, inspection, testing, printing equipment
* Materials Handling – automatic or manual lifts, table lifts, weighing, inspection equipment
* Transportation – special vehicles, GPS location systems, control equipment, traffic control
* Marine – lighting, control wiring and navigation equipment
* Security – alarm beacons, CCTV, detection systems
* Networking – LAN and wireless equipments
* Renewable energy – solar inverters

.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Eaton Moeller, one of the leading manufacturers of components and systems for electrical engineering and automation, is now offering a new gateway for SmartWire-DT in order to connect to Ethernet IP and Modbus TCP: The innovative SmartWire-DT communication system for networking control circuit and switching devices can now also be connected to controllers via an Ethernet/IP or Modbus-TCP network. The SWD-Assist planning and commissioning software is available for download free of charge from (www.moeller.net ).

This is made possible thanks to the new EU5C-SWD-EIP-MODTCP SmartWire-DT gateway which comes with a 10/100MBit switch and simplifies the configuration of linear structures. The additional diagnostics interface simplifies commissioning and helps users with any troubleshooting. The powerful SWD-Assist planning and commissioning software enables users to configure the SmartWire-DT network easily. The online function of the SWD-Assist in particular enables the first test of the switchboard installation to be carried without having to install a PLC. All inputs and outputs of the SmartWire-DT slaves can be exported simply and used in the PLC configurator of the controller manufacturer used (e.g. RSLogix 5000).

The software developed by Eaton Moeller for SmartWire-DT simplifies planning and enables the user-friendly testing and commissioning of all switching and control circuit devices. Version 1.40 onwards of SWD-Assist now also allows the configuration of the new EU5C-SWD-EIP-MODTCP gateway. The Ethernet IP / Modbus-TCP gateway enables an Ethernet-based connection to the SmartWire-DT system for the first time, so that Eaton Moeller is covering important fieldbus systems for commonly used controllers.

.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Robust, Instant Connections for Harsh Environments

6000 Series Buccaneer - circular connectors that combine the ease of use of a push/pull coupling mechanism with proven environmental sealing.  Available with metal or plastic bodies, the range supports Ethernet and USB data interfaces.

Designed and independently tested to IP66, IP68 & IP69K standards, they are ideal for applications where ingress of dust and water must be avoided and where ease of connection, space and appearance are important considerations.

For Data - USB
Thermal-Plastic Version

CLICK HERE FOR BROCHURE --->  Bulgin 6000 Series Buccaneer for Data USB

* Push-pull coupling locking system - Secure, instant locking. Quick connector mating and release
* 30° twist locking - Prevents accidental un-mating
* IP66, IP68 and IP69K when mated - Suitable for a wide range of dust and water borne environment
* Independent sealing tests - IP Ratings independently verified
* USB version 2.0 performance - Low and high speed bus connection, 1.5Mbs to 480Mbs
* Plug and play capability - Hot pluggable, standard 4 pole interface
* Shielded system - High noise immunity and EMI protection
* Visual mating indication - Alignment indicator reduces risk of damage during mating
* Single and double ended cables - Suitable for PC and peripheral configuration

6000 Series Buccaneer - specially designed for a broad range of harsh environment applications, including:

* Industrial Automation – assembly systems, conveyors, factory automation, motion and process control, factory peripherals, industrial computers, industrial controllers, testing, measurement and inspection equipment, vision systems
* Lighting – temporary lighting, external illumination, signage, architectural lighting
* Food Processing – feeding and packaging, weighing, inspection, testing, printing equipment
* Materials Handling – automatic or manual lifts, table lifts, weighing, inspection equipment
* Transportation – special vehicles, GPS location systems, control equipment, traffic control
* Marine – lighting, control wiring and navigation equipment
* Security – alarm beacons, CCTV, detection systems
* Networking – LAN and wireless equipments
* Renewable energy – solar inverters

.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Robust, Instant Connections for Harsh Environments

The all plastic construction 6000 Series Buccaneer - circular connectors that combine the ease of use of a push/pull coupling mechanism with proven environmental sealing for signal and mains power.

Designed and independently tested to IP66, IP68 & IP69K standards, they are ideal for applications where ingress of dust and water must be avoided and where ease of connection, space and appearance are important considerations.

For Power
Thermo-Plastic Version

CLICK HERE FOR BROCHURE --->  Bulgin 6000 Series Buccaneeer For Power

* Push/pull locking mechanism - Secure, instant locking. Quick connector mating and release
* 30° twist locking - Tamperproof lock prevents accidental un-mating
* IP66, IP68 and IP69K when mated - Suitable for a wide range of dust and water borne environments
* All plastic body version; UL94-V0 rated, UV stable, halogen free - Light-weight, self-extinguishing material suitable for long-term outdoor use
* Flex, flex in-line & panel mount body styles, with sealing caps - Complete family of products maintain sealing integrity in all styles
* Polarisation and visual alignment features - Aids the correct mating of connectors
* 2 to 22 poles – up to 16A, 277V rated - Suitable for mains power to signal applications
* ‘Scoop proof’ contacts - Prevents damage through mis-mating – ideal for ‘blind mating’ applications
* cULs, UL, VDE, CCC approvals (pending) - Internationally recognised certification

6000 Series Buccaneer - specially designed for a broad range of harsh environment applications, including:

* Industrial Automation – assembly systems, conveyors, factory automation, motion and process control, factory peripherals, industrial computers, industrial controllers, testing, measurement and inspection equipment, vision systems
* Lighting – temporary lighting, external illumination, signage, architectural lighting
* Food Processing – feeding and packaging, weighing, inspection, testing, printing equipment
* Materials Handling – automatic or manual lifts, table lifts, weighing, inspection equipment
* Transportation – special vehicles, GPS location systems, control equipment, traffic control
* Marine – lighting, control wiring and navigation equipment
* Security – alarm beacons, CCTV, detection systems
* Networking – LAN and wireless equipments
* Renewable energy – solar inverters

.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

The Honeywell V15W is a standard-sized basic switch designed for harsh-duty, wash down areas. Rugged yet precise, the series provides machine control for turning circuits on and off. The V15W can be used in a wide range of challenging environments, including food packaging plants, forklifts, atvs, golf cars, lawn mowers, garbage trucks, salt trucks, commercial buses, forklifts and wheelchair lifts for conversion vans. Choose the V15W when you need accurate repeatability in a compact, light weight and long lasting basic switch.

V15W Watertight Series:  Watertight switch in a V-size package. Watertight to an IP67 rating (switch body only). The V15W is designed for applications requiring >15 g operating force and electrical ratings from 0.1 A to 10 A.

- Rugged yet precise, the V15W product performance matches customer design expectations for compactness, accurate repeatability and extended life, giving them flexibility in a wide range of washdown applications
- For design engineering flexibility, the VW15 Series features a variety of straight, roller, simulated roller, and special actuators to choose from (connectors on lead wires also available)
- Many switch characteristics, are available to create thousands of different potential configurations
- Designed specifically for challenging outdoor applications, the V15W gives repeatable and consistent performance within a range of conditions
- Able to operate under difficult environmental conditions, the V15W Series is designed to work in watertight or sealed applications requiring ≥15g of operating force
- Rated to IP67 (except terminal parts)
- The only V-sized switch rated up to 10A!  The higher rating allows the V15W to be used in a wider range of high current consumer and industrial applications

The V15W Series is the standard miniature snap-action switch in Honeywell's Micro Switch portfolio of products that also includes standard Z, and premium Large, V, and S Series. The Honeywell V15W Watertight Series switches are often chosen due to their small size and sealing options when customers need to sense presence or absence in a compact package with accurate repeatability and extended life, at a great value.

KEY FEATURES AND BENEFITS
* Broad range of electrical loads
* Straight, roller, simulated roller, and special actuators
* Special terminations available upon request
* Wide temperature range
* Global approvals (UL, cUL, ENEC, CQC)

POTENTIAL APPLICATIONS
For use in applications where a pre-wired sealed on/off switch is required.

* ATV and Off-road Vehicles:  Brake light assemblies, brake position detection, handle bar controls, run-away prevention, shift lever position (golf carts), marine controls
* Construction and Agriculture:  Joystick controls, pushbuttons, seat position detection (lawn and turf), pedal position detection, run-away prevention, lighting controls, PTO position detection, position detection on attachments, position detection on hydraulic systems (wake-up)
* Industrial:  Washdown factory floor, factory machinery, pressure/temp/flow switches, motor-controls (on/off, auto-stop), ice makers, valve position
* Medical Equipment:  Hospital bed controls, dental chairs, foot-pedals, pneumatic switches

.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Schurter, as a leading supplier of EMC products is constantly improving the use of its products. The Schurter common mode chokes datasheets now contain impedance diagrams and cURus approval mark.

Current compensated chokes are used to attenuate asymmetrical noise. Such common mode noise is typical for switch circuits such as switching power supplies or inverters.  The compact chokes guarantee efficient disturbance suppression on the printed circuit board. Very compact types for surface mounting are also available as are chokes with wire leads for easy assembling for high power applications.

According to the noise level design engineers can easily select the right choke using the impedance diagram.  This may help to avoid many costly and time consuming measurements. Impedance diagrams are now available for all common mode chokes.

A safety certificate can be obtained even quicker due to the new UL approvals for our chokes.  All Schurter common mode chokes have now the combined UL and CSA approval mark cURus. They were successfully tested according to the UL 1283 and CSA 22.2 No. 8 standard. Approval marks and standards are now listed on all the data sheets.

Technical Features
- Rated Voltage 250 / 760 VAC
- Rated Current 300 mA - 50 A
- Rated inductance 0.5 mH - 100 mH
- Operating temperature -40 - 125 °C
- Multiple housing options available

Applications
- Switching power supplies
- Inverter
- Industrial electronic
- Lighting

.
