Sensata / Crydom - Panel Mount AC Output SSR Range

March 28, 2023

Our Panel Mount Solid State Relays are designed to easily mount on flat panels or heat sinks with screws through the SSR’s baseplate. Available in various industry standard sizes, the panel mount relay is currently the most used mounting type in the solid state relay market.

We offer standard and custom panel mount AC output SSRs available in single, dual, quad or 3-phase output configurations with current ratings from 1 to 150 Amps at 24 to 660 VAC and motor ratings of up to 25 HP at 480 VAC.

Sensata | Crydom’s extensive range includes screw terminals, quick connect terminals, optional protective covers, LED input indicators, and thermal interface pads, as well as heat sinks and other accessories, which facilitate the installation of a panel mount solid state relay in your application.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

For more information
We are happy to help!

Sensata / Crydom CS Series (Panel Mount AC Output) Solid State Relays

March 27, 2023

The CS Series of Panel Mount AC output Solid State Relays offer a back-to-back SCR output with ratings from 10 to 90 Amps at 24 to 280 VAC.

Features:
• 3-32 VDC control input range
• Low off-state leakage current (snubberless)
• LED input status indicator optional

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

For more information
We are happy to help!

Sensata / Crydom CL Series (Panel Mount AC Output) Solid State Relays

September 29, 2022

The CL Series Panel Mount AC output Solid State Relays offer a cost effective TRIAC output with ratings of 5 and 10 Amps at 24 to 280 VAC.

Features:
• AC or DC Control Input
• Zero Voltage (resistive loads) or Instantaneous (inductive loads) Turn-On Output
• LED Input Status Indicator

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

For more information
We are happy to help!

Cynergy3 IWVT Series

September 27, 2022

Industrial Wireless 0-10 Vdc Transmitter



The IWVT Wireless Transmitter is a cost effective alternative to traditional wiring that offers the advantages of a low-cost installation in inaccessible and expensive installation environments.

It is easily paired to any of the range of IWR receivers - thus offering a “plug and play” solution to your analog voltage application.

The IWVT sensor should be used with any of the IWR range of receivers. A line-of-sight range of up to 500 m is possible depending on the wireless receiver used (refer to specific receiver datasheets for further information).



Features:
• 0-10Vdc wireless transmission
• Up to 500 m line-of-site range (depending on receiver)
• Five-year battery life at 10 second transmission update rate
• Simple DIL switch pairing with the single or five channel receiver
• User-selectable transmission update rates
• A range of receivers are available
• Receiver clean contacts provide process alarm functions

Typical Applications Include:
• Simple cable replacement installation – dispense with expensive and tortuous cable runs
• Analog Sensor Status – transmit 0-10Vdc sensor outputs to a remote receiver



Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

For more information
We are happy to help!

Sensata / Crydom Evolution Dual Series (Panel Mount AC Output) Solid State Relays

August 12, 2022

The Evolution Dual family of Panel Mount dual channel AC Solid State Relays is an innovative line which expands upon the classic family of Crydom Dual SSRs, offering an improved mechanical and thermal design along with higher power density. These dual output SSRs are available with ratings of 25 and 50 Amps at 24 to 600 VAC.

Evolution Dual SSRs have 2 outputs controlled by 2 independent DC control inputs, and they are available with different options for input connectors and output terminal configurations, offering great wiring flexibility. A version with an integrated protective cover (IP20) is also available.

Features:
• 4-32 VDC control input
• Zero voltage turn-on outputs
• SCR output for heavy industrial loads
• Input status LED indicator for each channel
• C-UL-US recognized, CE & RoHS compliant

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

For more information
We are happy to help!

Cynergy3 IWTXT Series

August 11, 2022

Wireless 4-20 mA Transmitter with Tx Supply

The IWTxT is designed to convert any standard 4-20 mA transmitter into a wireless unit.

It works by switching on a supply to the 4-20 mA transmitter, waiting for a suitable settling time and then sending the data to one of Sensata’s standard wireless receiver units.

The IWTxT is specially designed to maximise battery life and in a typical application the battery life will exceed 12 months. The data update rate is user selectable to suit the requirement of each measured variable and so maximize battery life.

Typical update rates include 1 second, 10 seconds, 60 seconds or 1 hour. The system also features a signal strength reading and time since last transmission which can be remotely monitored.

The IWTxT is designed to operate with the IWR range of receivers. The IWR-1 can output a 4-20 mA or 1-5V signal whilst the IWR-PORT can store up to 128 variables for transmission to an industrial Ethernet connection or an RS-232/485 communications link.

Features:
• Battery powered wireless transmitter
• Supplies excitation voltage to 4-20 mA transmitters
• Long battery life
• Make any transmitter into a wireless transmitter
• Complete thermocouple, RTD, Pressure and Level wireless probes are available

Inputs:
The input types and ranges included below are our standard ones only (Contact Sensata for others).

DC Current & Voltage
• 0-20 mA, 4-20 mA, 0-10 mA into 15/30Ω
• 0-1V, 0-10V, 1-5V into 100kΩ/1MΩ

Any standard 4-20 mA transmitter



Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

For more information
We are happy to help!

Sensata / Crydom H1 Series (Panel Mount AC Output) Solid State Relays

June 27, 2022

The H1 Series is a family of high voltage panel mounted AC Solid State Relays with ratings from 25 up to 125 Amps at 48 to 660 VAC. Their back-to-back SCR output is ideal for heavy industrlal loads.

Features:
• DC control input
• Low off-state leakage current (snubberless)
• Zero voltage (resistive loads) or instantaneous (inductive loads) turn-on output
• Optional LED input status indicator
• L, CSA and TUV approved and CE compliant to EN 609050-1

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

For more information
We are happy to help!

Sensata / Crydom HA & HD Series (Panel Mount AC Output) Solid State Relays

May 24, 2022

The HA/HD Series Series is a family of panel mounted AC Solid State Relays with ratings from 12 to 125 Amps at 48 to 660 VAC.

Features:
• AC or DC control input
• Zero voltage (resistive loads) or instantaneous (inductive loads) turn-on output
• Optional LED input status indicator
• Optional low input current version
• UL, CSA and TUV approved and CE compliant to EN 609050-1

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

For more information
We are happy to help!

Cynergy3 IWR-USB Series

May 19, 2022

Wireless to USB Gateway



The IWR-USB Gateway provides a link between wireless sensors and any PC with a USB connection.

A free of charge software package allows monitoring and logging of all the sensors in the wireless network via a standard PC.

The IWR-USB saves the time-stamped data collected in a standard .csv file for easy handling by packages such as Microsoft® Excel®.







Features:
• 2.4GHz Wireless to USB Gateway
• Enables easy monitoring of our wireless networks using any PC
• Free of charge monitoring software allows all wireless parameters to be viewed and logged
• Logs data to .csv file

Multiple battery powered sensors transmit data at programmable intervals to a IWR-USB receiver which can then be connected to a standard PC for monitoring and logging the data from the wireless transmitters.  Data from up to 128 parameters can be accessed via the IWR-USB receiver.



Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

For more information
We are happy to help!

Sensata / Crydom PM67 Series (Panel Mount AC Output) Solid State Relays

April 28, 2022

The Nova22 PM67 is a compact 3-phase solid state relay in a panel mountable 67.5mm wide package with output ratings up to 75 Amps per channel @ 40°C. Its built-in overvoltage protection and the optional overtemperature protection make it suitable for demanding heating, motion and lighting applications.

It’s easy to install and its large cage clamp terminals allow connecting wires up to 2 AWG size on the output terminals without the use of any additional accessories, therefore reducing installation cost and time.

UL approved and VDE certified, the PM67 is a powerful and versatile solid state relay with superior performance when compared to previous generations and competitor products.

Features:
• Output ratings up to 75 Amps at 600 VAC
• 2 & 3 controlled Legs option
• Over Temperature protection w/alarm (optional)
• Built-in overvoltage protection
• Clamp Cage terminal type accepts up to 2 AWG wire size.
• Layout of mounting holes compatible with standard hockey puck SSRs
• IP20 touch-safe housing
• AC or DC control
• C-UL-US recognized and VDE approved

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

For more information
We are happy to help!
