NDK Control Circuit Transformers

1. General Information
* Electric ratings: AC 50Hz/60Hz
* Application: for control power supply of apparatus, partial illumination and indicator light of machine tool and other mechanic equipments
* Standards: IEC/EN 61558

2. Type Designation
* Rated ouput capacity (VA): 25VA~5kVA
* Control Transformer Series

3. Operation conditions
* Temperature: -5C ~ +40C the average value within 1 month should not exceed +30C and within 1 year +20C
* Altitude:≤2000m
* Relative humidity: ≤95%

4. Features
The transformer is characterized by excellent performances, reliable operation, compact design, safe wiring, and wide application, etc.

.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

The Crydom CTR Series of DIN Rail mounted Three-Phase AC Output Solid State Contactor Relays includes models with 25 amps per channel Output at 600 VAC, AC or DC Control Inputs, IP20 Touch Safe Design, UL approval and CE certification.

Crydom, a company of Custom Sensors & Technologies (CST) and global expert in Solid State Relay Technology, announces the introduction of the CTR Series of 90 mm wide three-phase DIN Rail mounted AC output SSRs.

The new Crydom CTR series offers UL approved AC output ratings of 25 amps per channel at 600 VAC, AC or DC input control, zero voltage or random turn on, and IP20 touch safe construction with integral heat sink. Mounting to industry standard 35 mm DIN rail, the CTR Series also includes compliance to the IEC CISPR 11 Class A emissions requirements, IEC61000-4-2 through -6, level 3, transient susceptibility standards, RoHS compliance, and CE Certification to the Low Voltage Directive.

.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

The new KF-series features exceptionally large isolation distances and offers high AC-23A motor ratings.  It covers the range from 16A to 32A and offers disconnect capability of up to 1000V according to IEC 947.  The rotary contact system incorporated in a new type of modular contact block allows high mechanical life expectancy and precise and reliable contact making.

The innovative modular system is both simple and very safe while offering enormous flexibility.  All available modules can be combined, exchanged or added in the field, as can the very precisely working cam-operated auxiliary contacts.  The position of the various modules in relation to each other
can be defined by the user or, if preferred, preassembled in the factory.

* Coupling profile determines pre-closing function of switched 4th pole,
  i.e. contact modules per se are always the same

* Rotating contact movement (instead of classical vertical lifting) allows
  big contact gaps
  high mechanical life expectancy
  very precise movement sequence
  self-cleaning contacts
  forced opening and closing of contacts

* Compact (very shallow) design

* Up to 1000V insulation voltage according to IEC possible

* Lateral drive possible (latching module not in the centre but on left or right hand side)

* Visible contacts (windows) available on request

* Design allows a big variation of terminal markings

* Removal from DIN rail can be done without tool change (screw driver for cross-recessed screws sufficient)

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

The 2009 edition of ABB’s drives and motors catalogue is now available for end-users, system integrators and Original Equipment Manufacturers (OEMs). The 48 page catalogue is free and can be downloaded directly from www.abb.co.uk/energy or a hard copy is available from freephone Brochureline on 0800 783 7491.

The catalogue provides technical details of ABB’s range of low voltage AC drives from 0.18 to 2,800 kW and motors from 0.06 to 710 kW. It also presents ABB’s range of DC and medium voltage AC drives. Easy-to-use tables give ordering data, dimensions, options and electrical details for most products, together with prices for 2009.

New products for this year include an IP66 rated ABB general machinery drive. From 0.37 to 7.5kW the drive is suitable for screws, mixers, pumps, fans and conveyors in places where the machinery is exposed to dust, moisture and high pressure washing such as the food and drinks sector. The ABB standard drive range and the ABB industrial drive range have also seen their power range boosted and are now available up to 160kW.

Supporting software includes integration and programming tools, start-up and maintenance tools, as well as engineering and energy saving tools. Web links tell readers where to download the different packages.

As well as product details, the 2009 brochure outlines the services available to support drives customers. DrivesActive, provides 24/7 support, while DrivesActive+ is a lifecycle management programme for critical equipment. DrivesAdvantage completes the service portfolio with installation, start-up and after-sales support.

The catalogue also includes details of the ABB Drives Alliance and Motor Service Partners located throughout the UK. The partners stock a wide range of ABB drives and motors, many available off-the-shelf or available for delivery at short notice.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Crydom has combined solid state and mechanical switching
technologies to create a contactor with longer operational life
than standard EMR's in an industry standard package!

Crydom, global expert in solid state relay technology, introduces a new line of high power Hybrid Solid State Contactors for use in Heating and Lighting applications where Mercury Displacement Relays have previously been applied, and where life cycle constraints limit the use of Definite Purpose Contactors.

crydom_rhp.pdf

Mounting identically to a standard 3 phase DP (Definite Purpose) contactor, and featuring full load life cycle ratings of greater than 2 million operations, the new RHP line includes 3 phase contactor configurations rated at 120, 240, 280 or 600 VAC at 40 or 50 amp load ratings per phase at 65 degrees C ambient temperature. Control voltages of 24, 120 or 220 VAC, and unique logic compatible 5, 12 or 24 VDC input control options are offered. The RHP line is UL and cUL approved and CE certified.

The RHP line incorporates Crydom's proven Hybrid SSR technology that utilizes contactless Solid State Relay turn on and turn off performance, coupled with the very low on state power dissipation characteristics of contactors, thus eliminating the need for heat sinking. The higher power switching capabilities of the new RHP line means that in those applications where Mercury Displacement Relays are no longer welcome, the OEM manufacturer now has a cost effective alternative available. Similarly, in applications where contactor life cycles are a limiting or maintenance cost concern, the new Crydom RHP Contactor provides significantly longer operational life capability in an identical mounting package.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Crydom Solid State Relays (SSRs) are widely used in applications where controlling different types of motors is necessary. They are used for AC motor speed control, motor reversing, starting motors, soft starting and soft stopping of motors, motor starting switches of both single phase and three phase motors.

Crydom SSRs are also used to control DC motors.  DC relays can be used as a switch, for reversing DC motors, or using PWM (Pulse Width Modulation) for DC motor speed controls.

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

The new CT-S range is ABB’s latest development of universal time relays. This range comprises of 13 single-function devices and 8 multifunction timers with up to 11 functions, offering a high flexibility in operation. All devices have adjustable time delays from 0.05 seconds to 300 hours in 10 time ranges. The new CT-S range is prepared for all markets world wide. The products are cULus 508, CB scheme, CCC, GL, RMRS, GOST approved and CE and C-Tick marked.

Characteristics of the CT-S range
• Control supply voltages:
     o Multi ranges: 24...48 V DC, 24...240 V AC
     o Wide range: 24...240 V AC/DC
     o Single range: 380...440 V AC
• Devices with:
     o 1 or 2 c/o contacts
     o 2nd c/o contact can be selected as instantaneous contact1)
• Remote potentiometer connection1)
• Control input with volt-free or voltage-related triggering e.g. to start timing, pause timing
• Sealable transparent cover for protection against unauthorized changes of time and threshold values
• Integrated marker label

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

Only reliable, continuous monitoring of the three-phase supply can ensure  trouble-free and efficient operation of motors, machines and equipment. ABB now offers a comprehensive range of 22.5 mm, within the CM series, to protect sensitive equipment from adverse three-phase voltages. The product range extends from the full protection
multifunction three-phase monitor, CM-MPS, to single-function devices for monitoring single parameters.

The CM-MPS is a multifunction monitoring relay. It monitors all phase parameters including: phase sequence, phase failure, over- and undervoltage and phase unbalance. It is available with or without monitoring of the neutral conductor. Seven devices with a graded scope of functions complete the CM product range. The new devices for three-phase voltage monitoring, CM-PVS and CM-PSS along with the CM-PAS for monitoring phase unbalance, offer functions adapted to the relevant requirements and facilitate the accurate monitoring of three-phase mains.

The characteristics of the three-phase monitors are:
• Phase failure monitoring
• Phase sequence detection*
• Over- and undervoltage monitoring (fixed or adjustable)*
• Adjustable phase unbalance threshold*
• Adjustable delay time, and selectable ON-delay or OFF-delay function*
• Dual-frequency,  50/60 Hz operation
• Powered by the measuring circuit
• 1 n/o, 1 or 2 c/o  contacts
• LED for status indication
• Wide operating voltage range

*Depends on device type

Enquiry Form: https://www.epreston.co.uk/contact/

Home Page: https://www.epreston.co.uk/epblog/

ABB has significantly enlarged its range of switch-mode power supply devices (SMPS). Supplementing the existing range of tried and tested SMPS products of the CP series for nominal currents of 0.3A up to 20A, there are now new CP-S and CP-C series for the range between 5 to 20A available.

The SMPS devices of the CP-C series are characterized by their modular, plug-in functional modules that extend the functionality of the devices tailored to the requirements of the customer. The CP-C MM signal module for example monitors the input and output voltage, and has a remote-OFF function. More plug in modules are under preparation.

There are also manifold applications for the CP-S devices that – while offering the same modern and powerful technology – dispense with some of the extra features of the CP-C series.

All power supply units of the CP, CP-S and CP-C series are primary SMPS: they guarantee the best possible efficiency (>88%), minimized losses, environmental compatibility and cost efficiency.

Characteristics:
CP-S range
• Selectable input voltage 85-132VAC/184-264VAC, 220-350 V DC
• Fixed output voltage

CP-C range
• Autorange input 85-264VAC, 100-350VDC
• Adjustable output voltage 22-28VDC
• PFC (power factor correction)

The new CP-S and CP-C range power supplies feature power reserve of up to 50%. The 5A and 10A models have pluggable, double connection terminals, and LED indication "OUTPUT OK". All of them are CE marked, the C-Tick mark and the cULus (508) and UL60950 approvals are under preparation.
