Category Archives: Circuit Breakers / Circuit Protection Devices

E-T-A Publishes Two New, Comprehensive, Product Catalogues

 eta logo.jpg

E-T-A Circuit Breakers has published new 2006/07 editions of its separate CBE (Circuit Breaker for Equipment) and Control Products catalogues, which can be requested free by telephone, email or from the company web site. Providing comprehensive technical details, the catalogues have been expanded to include all the latest product developments.

E-T-A CBE Cat  2006 7.jpg         E-T-A Control Products Cat 2006 7 (2).jpg

The latest 2006/07 edition of E-T-A’s Circuit Breakers and Control Products / CBE Catalogue now runs to over 500 pages.  The 100 page increase reflects, in particular, the expansion of products offering electronic overcurrent protection for selective protection of components in industrial plants, as well as solid state remote power controllers and power distribution systems.  The catalogue provides a complete specification of each E-T-A product and is broken down into 10 clearly thumb-tabbed sections. These sections also include four different classifications of CBEs and explanations of their characteristics and how to choose between them for a given application.

The 2006/07 edition of E-T-A’s Electronic Process Sensors – Electronic Switching and Control / Control Products Catalogue contains 410 pages with 9 thumb-tabbed sections, again including all the latest products. Sections include flow meters and monitors, level and velocity sensors, digital panel instruments, and current and voltage monitors.  All sections are clearly indexed with summary overviews and contain descriptive details of every product. Photographs and fully dimensioned drawings are included, together with technical data, CBE switching characteristics and product ordering information.

Copies of the two catalogues can be requested from E. Preston (Electrical) Ltd (0161 339 5177), e-mail  sales@epreston.co.uk or via the web site at http://www.epreston.co.uk/, which also offers further information on the E. Preston Electrical range of products.



Enquiry Form: http://www.epreston.co.uk/enquiries.php

Home Page: http://www.epreston.co.uk/epblog/

Finder Introduces Phase-Monitoring Relay that Prevents Phase Loss Causing Motor Burnout


Finder introduces the 72.31 three-phase monitoring relay, which is used for detecting a loss of phase or incorrect phase rotation when using three-phase supplies. This compact relay is ideally suited for the protection of motors in plant and machinery, and helps to satisfy the mandatory requirement of ensuring the correct rotation of motors in transportable equipment.

The 72.31 allows OEMs, panel builders and installers of control systems to ensure that motors do not become permanently damaged due to phase loss, and also to avoid potential hazards or damage due to incorrect rotation of the motors. The relay features positive safety logic, which triggers the contact to open if an error is detected so that the system will fail to a safe condition. The wide supply voltage specification allows a single unit to be used across the full three-phase supply voltage range of 208V to 480V AC.

FIN0036 7231.jpg

The relay provides reliable monitoring of phase loss, even under conditions where the lost phase may be “regenerated” by the action of the rotating motor. This phenomenon is not uncommon, and many monitoring relay units that are currently available may falsely detect this phase regeneration and thus fail to disconnect the supply, which can cause damage to the motor. The 72.31 can discriminate phase regeneration up to 80% of the line voltage.

Featuring a SPDT output contact rated at 6A (maximum peak 15A), the 72.31 monitoring relay is enclosed in a compact housing measuring 84mm high x 56.5mm deep x 17.5mm wide. The narrow profile offers considerable saving in panel space.



Enquiry Form: http://www.epreston.co.uk/enquiries.php

Home Page: http://www.epreston.co.uk/epblog/

E-T-A, Stylish ‘Water-Splash’ Protected Switch / Circuit Breaker

“Matching 3-position switch version available for 2-speed fans, wipers, etc.”

eta logo.jpg

E-T-A Circuit Breakers has introduced a new combined switch and circuit breaker for push-fit mounting in switch panels. Its attractive, contoured, ‘soft’ feel rocker actuator with dual illumination and choice of both colour and ‘marine’ legends make it a first-line choice for builders of power-boats and yachts. A 3-position switch version of matching design enables all combinations of switching and circuit protection to be provided in one stylish control panel grouping.

A0304eta - E-T-A 3131.jpg

The new E-T-A 3131 combined switch and thermal overcurrent circuit breaker provides snap-in, panel-mounted, single pole protection against both limited short circuits and low level, but potentially very harmful, overload currents. The integral overload protection negates the need for fuse holders or additional circuit breakers, thus offering great advantages for boat users and simplifying the wiring circuits. Models are offered in current ratings from 0.1A to 20A at up to 50V DC/240V AC for single pole applications. The complementary E-T-A 3131 three-position switch with matching actuator design offers the additional switching required for units such as 2-speed fans and wipers.

The ergonomically styled rocker actuator on both versions of the E-T-A 3131 is soft to the touch and offers two illumination options with a number of different permutations possible.   Splash water protection is assured even in the toughest nautical conditions with its IP66 rating. The 3131 CBE is one of the smallest and lightest products of this type on the market, making it ideal for the protection of circuits and equipment including vital navigation and communication equipment.



Enquiry Form: http://www.epreston.co.uk/enquiries.php

Home Page: http://www.epreston.co.uk/epblog/

New ABB Relay Offers Extensive Protection for Feeder Applications


ABB Limited has launched a new microprocessor-based relay device offering comprehensive protection for utility, industrial and marine feeder applications. Featuring a wide range of protection functions, the REF610 feeder protection relay offers a versatile device for protection of incoming and outgoing feeders as well as back-up for motors, generators and transformers.

The REF610 provides complete protection against overcurrent and earth faults. In addition to single, two and three-stage overcurrent and earth fault protection functions, the REF610 also features thermal overload protection, phase discontinuity protection, trip-circuit supervision and multi-shot auto-reclosing for automatic clearing of line faults.


Where an electrical disturbance or fault does occur, its details are recorded by the REF610’s in-built disturbance recorder, triggered by a start or a trip signal or by a digital input signal. Utilising microprocessor technology, the recorder collects instantaneous values or RMS values of measured signals via four analogue channels or up to eight selectable digital channels.

Based on a withdrawable ‘plug and play’ cassette design, the REF610 can be easily fitted and removed, greatly reducing the amount of downtime required for installation, testing and maintenance. Based on two separate units, this design automatically closes off the current transformer when the unit is removed, enabling work to be carried out safely without shutting off the supply.

Added reliability is ensured by the inclusion of a self-supervision system that continuously monitors the operation of both the relay electronics and software and ensures that users are alerted of any faults. This, combined with a long mean time between failure (MTBF), enables the REF610 to offer high availability.

A key strength of the REF610 is its user-friendliness. Parameters are displayed in plain text on an LCD screen. These parameters can be programmed using the push buttons on the front of the unit, via serial communication using a computer connected to the communication port or remotely through a control or monitoring system connected through the unit’s serial communication bus.

The REF610 features a range of communication options, including SPA-bus slave, MODBUS, IEC 60870-5-103 and DNP 3.0. It can also communicate wirelessly with a laptop computer if required.

The REF610’s compact size and small mounting depth makes it ideal for retrofits and confined space installations. Optional mounting kits for 19″ racks, as well as for semi-flush mounting with raising and 45° tilted raising frames also offers a choice of installation arrangements.
