Sensata / Crydom HA & HD Series (Panel Mount AC Output) Solid State Relays



The HA/HD Series Series is a family of panel mounted AC Solid State Relays with ratings from 12 to 125 Amps at 48 to 660 VAC.

Features:
• AC or DC control input
• Zero voltage (resistive loads) or instantaneous (inductive loads) turn-on output
• Optional LED input status indicator
• Optional low input current version
• UL, CSA and TUV approved and CE compliant to EN 609050-1



Enquiry Form: http://www.epreston.co.uk/enquiries.php

Home Page: http://www.epreston.co.uk/epblog/

Cynergy3 IWR-USB Series

Wireless to USB Gateway



The IWR-USB Gateway provides a link between wireless sensors and any PC with a USB connection.

A free of charge software package allows monitoring and logging of all the sensors in the wireless network via a standard PC.

The IWR-USB saves the time-stamped data collected in a standard .csv file for easy handling by packages such as Microsoft® Excel®.







Features:
• 2.4GHz Wireless to USB Gateway
• Enables easy monitoring of our wireless networks using any PC
• Free of charge monitoring software allows all wireless parameters to be viewed and logged
• Logs data to .csv file

Multiple battery powered sensors transmit data at programmable intervals to a IWR-USB receiver which can then be connected to a standard PC for monitoring and logging the data from the wireless transmitters.  Data from up to 128 parameters can be accessed via the IWR-USB receiver.



Enquiry Form: http://www.epreston.co.uk/contact/

Home Page: http://www.epreston.co.uk/epblog/

Sensata / Crydom PM67 Series (Panel Mount AC Output) Solid State Relays

The Nova22 PM67 is a compact 3-phase solid state relay in a panel mountable 67.5mm wide package with output ratings up to 75 Amps per channel @ 40°C. Its built-in overvoltage protection and the optional overtemperature protection make it suitable for demanding heating, motion and lighting applications.

It’s easy to install and its large cage clamp terminals allow connecting wires up to 2 AWG size on the output terminals without the use of any additional accessories, therefore reducing installation cost and time.

UL approved and VDE certified, the PM67 is a powerful and versatile solid state relay with superior performance when compared to previous generations and competitor products.





Features:
• Output ratings up to 75 Amps at 600 VAC
• 2 & 3 controlled Legs option
• Over Temperature protection w/alarm (optional)
• Built-in overvoltage protection
• Clamp Cage terminal type accepts up to 2 AWG wire size.
• Layout of mounting holes compatible with standard hockey puck SSRs
• IP20 touch-safe housing
• AC or DC control
• C-UL-US recognized and VDE approved



Enquiry Form: http://www.epreston.co.uk/enquiries.php

Home Page: http://www.epreston.co.uk/epblog/

Cynergy3 IWR-Port Series

Wireless to Ethernet or RS-232/485 Gateway

The IWR-PORT Ethernet Gateway provides a link between wireless sensors and sensor networks and Industrial Ethernet or RS-232/485 networks.

This allows Sensata wireless transmitters to be incorporated into new or existing Industrial Ethernet or RS-232/485 data monitoring and control networks.

The IWR-PORT can interface with standard 10/100Base-T Ethernet networks giving access to the standard MODBUS TCP protocol, ensuring compatibility with most industrial automation systems. MODBUS RTU is available when an RS-232/485 network is used.



Features:
• 2.4GHz Wireless to Comms Gateway
• Enables easy add-on of wireless networks to existing Ethernet or RS-232/485 systems
• Allows remote sensors to be incorporated into an Ethernet or RS-232/485 network without the need for expensive cabling
• Optional analog & digital outputs can be obtained using SCISOSLICE modules

Multiple battery powered sensors transmit data at programmable intervals to an IWR-PORT receiver which can transfer the data onto an Ethernet or RS-232/485 network.

Data from up to 128 nodes can be stored on one IWR-PORT module and up to 16 networks can co-exist together. All parameters are stored as Modbus registers.



Enquiry Form: http://www.epreston.co.uk/contact/

Home Page: http://www.epreston.co.uk/epblog/

Sensata / Crydom PM22 Series (Panel Mount AC Output) Solid State Relays

The Nova22 PM22 Series is a family of 22.5mm wide panel mount Solid State Relays that offer the highest power density in the market with ratings up to 95 Amps at 600 VAC. PM22s have a contactor terminal configuration which includes a plug-in connector for the control input, available in either standard “screw” or “spring cage” terminals.

PM22 Series models are C-UL-US and TUV approved.

Features:
• Built-in overvoltage protection
• DBC substrate for superior thermal performance
• IP20 touch-safe housing
• AC or DC control
• Zero voltage or instantaneous turn-on output
• 4000 VAC optical isolation





Enquiry Form: http://www.epreston.co.uk/enquiries.php

Home Page: http://www.epreston.co.uk/epblog/

Sensata / Crydom EL Series (Panel Mount AC Output) Solid State Relays

EL Series AC output solid state relays come in a compact, 21mm x 35mm housing and offer ratings up to 30 Amps. These compact SSRs come with a pre-installed thermal pad, input LED status indicator, optional built-in overvoltage protection, and are C-UL-US and TUV certified and CE compliant.

The EL Series mechanical design includes quick connect terminals and an innovative 90° bent terminals option ideal for applications with limited vertical space.

Additional Features of the EL Series Panel Mount AC SSRs Include:
• Load current ratings from 5 to 30 Amps @ 24-280 VAC
• Back-to-back SCR output with low off state leakage current
• Flexible 5, 12 and 24 VDC control voltage options
• Zero voltage or instantaneous turn-on outputs
• Plastic housing with min. 250 CTI rating (PLC2) for demanding applications



Enquiry Form: http://www.epreston.co.uk/enquiries.php

Home Page: http://www.epreston.co.uk/epblog/

Cynergy3 IWPT Series – Industrial Wireless Pressure Transducer

The IWPT Wireless Pressure Transducer is a cost effective replacement to a traditionally wired pressure transducer that offers the advantages of a low-cost installation in inaccessible and expensive installation environments.

It is easily paired to any of the range of IWR receivers – thus offering a “plug and play” solution to your pressure measurement applications.

The instrument uses a piezo-resistive ceramic sensor mounted within a 316 stainless steel housing giving excellent media compatibility for the harshest of applications. A swivel adapter is available which allows the head to be easily aligned to the IWR receiver – see IWPT-SA.

The IWPT sensor can be used with any of the IWR range of receivers. A line-of-sight range of up to 500 m is possible depending on the wireless receiver used (refer to specific receiver data sheets for further information).

Each device is temperature compensated, calibrated and supplied with a traceable serial number.

Features:
• Pressure ranges from -1 to +400 bar gauge
• Up to 500 m line-of-site range (depending on receiver)
• Piezo-resistive thick film ceramic sensor with stainless steel body
• Five year battery life at 10 second transmission update rate
• Simple DIL switch pairing with the single or five channel receiver
• Single, five and multi-channel channel receivers available (up to 128)
• User-selectable transmission update rates
• Analog, digital, RS-232/485, Ethernet & USB receiver outputs
• Receiver clean contacts provide process alarm functions
• Suitable for liquids and gases

Typical Applications Include:
• Simple cable replacement installation – dispense with expensive cable runs
• Environmental monitoring – pumping stations, sewage plants, water treatment
• Facilities management – boiler rooms, plant hydraulics, plant pneumatics
• Asset monitoring – tanks farms, process plants, HVAC and building management
• Service Contract – temporary installation for servicing and field trials



Enquiry Form: http://www.epreston.co.uk/contact/

Home Page: http://www.epreston.co.uk/epblog/

Sensata / Crydom CW Series (Panel Mount AC Output) Solid State Relays

The CW Series Panel Mount AC output Solid State Relays offer a back-to-back SCR output for reliable switching of commercial and heavy industrial loads. This type of high performing SSR is available with output ratings from 10 Amps up to 125 Amps at 24 to 660 VAC.

The CW Series panel mount solid state relay includes a removable IP20 touch-safe cover for added safety and is also available with zero voltage turn-on (for resistive loads) or instantaneous turn-on (for inductive loads) outputs.

Additional Features of the CW Series Panel Mount SSRs Include:
• DBC substrate for superior thermal performance:
• 3-32 VDC, 18-36 VAC, 90-280 VAC and universal AC/DC control input options
• LED input indicator
• EMC compliant to Level 3
• C-UL-US recognized, CE and RoHS compliant



Enquiry Form: http://www.epreston.co.uk/enquiries.php

Home Page: http://www.epreston.co.uk/epblog/

Cynergy3 IWPTU Series – Industrial Wireless Pressure Transducer

The IWPTU Wireless Pressure Transducer is a cost effective replacement to a traditionally wired pressure transducer that offers the advantages of a low-cost installation in inaccessible and expensive installation environments.

It is easily paired to the compatible IWR family of single- or five-channel wireless receivers thus offering a “plug and play” solution to your pressure measurement applications.

The instrument uses a piezo-resistive ceramic sensor mounted within a 316 stainless steel housing giving excellent media compatibility for the harshest of applications.

The IWPT sensor can be used with either an IWR-1 or IWR-5 receiver. A line-of-sight range of up to 1640 ft is possible depending on the wireless receiver used. (refer to datasheets IWR-1 & IWR-5 for further information)

Each device is temperature compensated, calibrated and supplied with a traceable serial number.



Features:
• Suitable for use with liquids and gases
• Pressure ranges from -15 to +5800 psi gauge
• Up to 1640 ft line-of-site range (depending on receiver)
• Piezo-resistive thick film ceramic sensor with stainless steel body
• Five-year battery life at 10 second transmission update rate
• Simple DIL switch pairing with the single or five channel receiver
• Single or five channel receivers available
• User-selectable transmission update rates
• User-selectable 1-5V or 4-20 mA receiver outputs
• Receiver clean contacts provide process alarm functions

Typical Applications Include:
• Simple cable replacement installation – dispense with expensive cable runs
• Environmental monitoring – pumping stations, sewage plants, water treatment
• Facilities management – boiler rooms, plant hydraulics, plant pneumatics
• Asset monitoring – tanks farms, process plants, HVAC and building management
• Service Contract – temporary installation for servicing and field trials



Enquiry Form: http://www.epreston.co.uk/contact/

Home Page: http://www.epreston.co.uk/epblog/

Sensata / Crydom Series 1 (Panel Mount AC Output) Solid State Relays




The Series 1 is Sensata | Crydom signature family of Panel Mount AC output Solid State Relays with reliable back-to-back SCR output for heavy industrial loads. These SSRs are available with ratings from 10 Amps up to 125 Amps at 12 to 530 VAC.

Additional Features of the Series 1 Panel Mount SSRs Include:
• DBC substrate for superior thermal performance
• AC or DC control input
• Zero voltage (resistive loads) or instantaneous (inductive loads) turn-on output
• Optional LED input status indicator
• UL, CSA and TUV approved and CE compliant to EN 609050-1
